Star Sensor
2025年9月3日CMOS focal surface
2025年9月3日
| Product code | CG-DJ-PD-100 | CG-DJ-PD-300 |
| Envelope size | 94mm×94mm×46mm | 150mm×120mm×57mm |
| Weight | 0.5kg | 1.3kg |
| Power consumption | 1W | 8.5W (including DCDC quiescent power consumption) |
| Power distribution | 10 channels 12V/7 channels 5.2V | 6 channels 28V/8 channels 12V/5 channels 5.2V |
| Heating belt driven | 11 channels with a maximum of 2W per channel | 15 channels with a maximum of 10W per channel |
| Temperature/analog acquisition | 20-way 12-bit acquisition | 34 channels 12-bit acquisition |
| SADAdrive | 2 ways | \ |
| Fuse control | 2 channels with a current of 4~6A. | 2 channels with a current of 5~6A. |
| Delivery cycle | 4 months | 4 months |
